CL9 AeroShell LGF Aircraft Hydraulic Fluids Mineral Shock Absorber Fiuid

AeroShell LGF  - Hydraulic Fluids Mineral Shock-Absorber Fiuid For Aircraft

AeroShell Landing Gear Fluid (LGF) is a mineral hydraulic fluid (MIL-PRF-5606) to which additional additives havebeen added to improve the extreme pressure characteristics and the fluid’s natural lubricity. The lubricity agentprovides a stable thin film layer to the metal surfaces at mild operating conditions. When severe conditions exist(landing/ touchdown), the extreme pressure additive supplies the load carrying needed at the metal-to-metal surfacesto prevent the occurrence of such phenomena as "ladder cracking" and "slip stiction" of the piston component of thelanding gear. AeroShell LGF is AeroShell Fluid 41 plus additives.

Main Applications

The excellent low temperature properties of AeroShell LGFmake it particularly suitable in areas of low temperatureoperations.AeroShell LGF is straw yellow in colour.

Specifications, Approvals & Recommendations

AeroShell Landing Gear Fluid (LGF) is not covered by anymilitary specification.·McDonnell Douglas Approved DPM-6177 ·Boeing Approved BMS 3-32A (AeroShell LGF is approved toType II)·

AeroShell LGF is approved for use in the shock struts of thefollowing aircraft

Boeing 707/720, 727, 737, 747 (except those using BMS 3-11 fluids), 757, 767 and 777

Lockheed L1011 Tristar

McDonnell Douglas DC-8, DC-9, DC-10, MD-80, MD-11

Airbus CML Code 02-004A (SSF)

For use in the landing gear shock struts of other aircraft,operators must check with the respective manufacturer first.

For a full listing of equipment approvals and recommendations,please consult your local Shell Technical Helpdesk, or the OEMApprovals website.

Compatibility & Miscibility

AeroShell LGF is compatible with AeroShell Fluids 4, 41 and71.

Typical Physical Characteristics
