Industrial Control Device Honeywell CD-830 P/N G7830-03/ P/N G7830-02 Optimal Performance

The Honeywell CD-830 is a rugged, high-performance rotary position sensor designed for demanding industrial and aerospace applications. It is known for its durability, precision, and ability to operate in harsh environments.

Key Features of the Honeywell CD-830:

• High Accuracy: Provides precise angular position measurement.
• Rugged Design: Built to withstand harsh environments, including extreme temperatures, vibration, and shock.
• Non-Contact Technology: Uses Hall-effect sensing, which ensures long life and reliability by eliminating mechanical wear.
• Wide Operating Temperature Range: Typically operates in temperatures from -55°C to +125°C (-67°F to +257°F).
• Multiple Output Options: Available in analog (voltage or current), digital, or custom output signals.
• Compact and Lightweight: Suitable for applications where space and weight are critical.

Typical Applications:

• Aerospace: Flight control systems, throttle position sensing, and landing gear position feedback.
• Industrial: Heavy machinery, robotics, and automation systems.
• Military: Defense systems requiring high reliability and durability.

Installation and Integration:

• Mounting: The CD-830 is typically mounted directly to the rotating shaft or mechanism being measured. Ensure proper alignment to avoid measurement errors.
• Wiring: Connect the sensor to the control system using the appropriate wiring harness or connectors. Follow the pinout and wiring diagram provided in the datasheet.
• Calibration: Some configurations may require calibration to ensure accurate position measurement.
• Testing: Verify the sensor's output and performance under operating conditions.

Contact us for prices.
